Security Control Panel 8 Partitions AV2016DP


Security Control Panel 8 Partitions AV2016DP

AV-2016 Series 2000 Security Expandable Control Panel, 16 or 32 zones
Security Control Panel 8 Partitions AV-2016DP
Alarm Panel with integrated PSTN dialer and communicator
Series 2000 Security Expandable Control Panel 16 zones for LED keypad
Professional level expandable Control Panel up to 32 zone, all double-zone type
Compatible with Av-Gad LED Keypads
Quality high-end alarm system with extreme flexibility features
Supports up to 16 user codes, installer code, access control code
Build in modem for remote programming via phone line
Programmable auto arming by day and time
Daily testing signal to central station
Jumbo size metal enclosure space for 2 SLA batteries
The 8 Partitions provides arming and disarming per partition
Compatible with EasyLoad PC software
High reliability, friendly and simple programming via keypad or PC
Remote Up and Download via modem or AV-232

Meet the essential requirements and is in conformity EN50131 grade IV

SKU: AV2016DPE

Security Control Panel 8 Partitions AV2016DP

AV-2016 Series 2000 Security Expandable Control Panel, 16 or 32 zones
Security Control Panel 8 Partitions AV-2016DP
Alarm Panel with integrated PSTN dialer and communicator
Series 2000 Security Expandable Control Panel 16 zones for LED keypad
Professional level expandable Control Panel up to 32 zone, all double-zone type
Compatible with Av-Gad LED Keypads
Quality high-end alarm system with extreme flexibility features
Supports up to 16 user codes, installer code, access control code
Build in modem for remote programming via phone line
Programmable auto arming by day and time
Daily testing signal to central station
Jumbo size metal enclosure space for 2 SLA batteries
The 8 Partitions provides arming and disarming per partition
Compatible with EasyLoad PC software
High reliability, friendly and simple programming via keypad or PC
Remote Up and Download via modem or AV-232

Meet the essential requirements and is in conformity EN50131 grade IV

Dialer & Communicator
Dials to 4 numbers via PSTN
One Follow Me number
Dials to 2 different central stations in Contact ID

Remote Control
DTMF control via mobile: Arm, disarm, dialer stop, zone bypass, alarm status
Optional four functions Wi-Fi add on. Item AVS_WF4
Optional RF radio remote control
Remote key for arm and disarm

Technical
On-board zones: 16 double zones
Expandable: by 16 zones add AV-816
PGM outputs: 6
Siren output: Two separated fused siren outputs
Keypad compatibility: AV-701, AV-701TI, AV-702 LED keypads
Keypads support: 6
Remote key: RF or Key Switch
Remote arm/disarm: Mobile DTMF
Remote Wi-Fi arming: Optional with AVSWF4
Communication: PSTN and GSM optional
Central station reporting: Contact ID to 1-2 centers
Expand to dial via GSM: AVG-13
Voice message: Optional by adding SVM voice module
Smoke reset: Available via keypad
Events buffer: 250
User codes: 16 codes, 1 programming code, 1 access control code
Auxiliary power: 17V, 1.5A DC or AC
Operating temperature: -20 to +60º C
Enclosure: Jumbo box, space for two 9A/H batteries
Dimensions: 35 x 32 x 9 cm (13 3/4” X 12 1/4” X 3 1/2)
