Power Supply & UPS AV21


Mini Power Supply & UPS

Power supply and UPS board only
Mini Central UPS for security and CCTV with battery back up
UPS for small security systems, LED lights
Provides 12V DC at 1.5A (15W)
Central Power Supply & UPS for alarm system and CCTV cameras
Allows operating voltage & backup battery to perimeter alarm detectors
Battery backup keep the system powered at power fail
Smart charger with battery monitor
The output is thermal fuse protected
LED indicators for AC and output channel
Keep working during power failure as a result of malfunction or AC power loss
Space inside the enclosure for rechargeable battery 5 or 7 or 9 A/H
Improved EMI and RFI protection designed for rush environment

SKU: AV-21e

Mini Power Supply & UPS

Power supply and UPS board only
Mini Central UPS for security and CCTV with battery back up
UPS for small security systems, LED lights
Provides 12V DC at 1.5A (15W)
Central Power Supply & UPS for alarm system and CCTV cameras
Allows operating voltage & backup battery to perimeter alarm detectors
Battery backup keep the system powered at power fail
Smart charger with battery monitor
The output is thermal fuse protected
LED indicators for AC and output channel
Keep working during power failure as a result of malfunction or AC power loss
Space inside the enclosure for rechargeable battery 5 or 7 or 9 A/H
Improved EMI and RFI protection designed for rush environment
Used as emergency light systems to keep light on at power failure
AV-21 UPS has 50% higher efficiency compared to AC UPS and at 50% lower price
Option: Output to activate dialer during malfunction or low battery

Technical details
Output voltage: 13.6 DC volts. Option Voltage 24 volts
Output current: 1.5A
Channels: One channel plus charger
Input voltage: 110 to 220 volts
Connections: Terminal wires for thick wires
Protection: Electronic 2A thermal fuse (PTC)
Charger: Includes battery monitor for maximum protection on battery
Battery type: 12V SLA (sealed lead acid)
Battery connector: Quick connector
Operating temperature: -20 to +80ºC (-4 to 176ºF)
Enclosure: None
Dimensions: 125 X 40 m”m

Benefits to the installer
Power supply board only
Protects against power fail
50% higher efficiency compared to AC UPS
Suitable for all alarm CCTV 12V or 24V systems
Quality service free device
