Mini magnetic switch for indoor AMS9

Mini magnetic switch for indoor

Mini magnetic switch for indoor applications
Micro nini magnetic switch fits hard to reach locations
UL listed magnetic switch contact
Magnetic switch for indoor security applications
Super Low Profile Design magnetic switch
Used for protecting doors and windows
Small magnetic contact with wires terminal
Magnetic side made of Alnico 5 magnet
Operation Gap Distance is 12 mm
Self-adhesive and screw mount
Supplied in Gift Bag 10 Pieces each
Supplied in Ivory color
Small size magnetic switch L=26, W=11, H=6.5 mm
Flexible Mounting Small size magnetic switch, screws or
adhesive tape

Main Features
UL listed magnetic contact
Super small size magnetic switch
Simple wiring
Attached with small screws
For hard to reach doors and windows
Economical model
Easy and Fast installation

Technical
Magnetic switch contacts: Wires terminal 30 c”m long (12″)
Magnetic Sensor: Reed switch
Type: Surface Mount contact
Operation Gap Distance: 12 mm (1/2″)
Contacts: One pair, Form A, N.O.
Magnet: Alnico 5
Colors: Ivory as standard
Enclosure: Plastic
Maximum Breakdown Voltage: 200V DC
Maximum Switching Current: 300 mA
Outdoor rating: none, indoor only
Operation Temperature: 0°C to 49°C (32°F to 120°F)
Dimensions: L=26, W=11, H=6.5 mm
Origin: USA

What is magnetic switch?
The magnetic switch is an electric switch that is sensitive to a magnetic field.
A magnetic switch is made up of a two parts; the switch is in a hermetically sealed glass shell, which has a Reed type
switch, 2nd part is the magnet.

The contacts may be open or closed, closing when the magnetic field is in place, and opening the contacts that
a magnet is moving away.
The switch is activated by bringing a magnet near the switch, the magnet is removed and the switch changes mode.
The gap parameter is the distance that the magnet affects the switch. Average gap is between 10 and 60 mm.
Gap is an important parameter, measured on none metallic surface.
