Telephone Line Monitor

Telephone Line Monitor Tele-Spy

Telephone Line (also called PSTN) monitor device
The Tele-Spy is a 24 hours telephone line monitor
Telephone line monitor protects the alarm ability to reports central station
Telephone line Monitor detects line short or telephone line cut
Telephone line Monitor protects against thunder hits
Monitors single telephone line for failure due to tampering or malfunction
Interfaced to phone line via isolated buffers for higher security
Test the line for 30 seconds continuity fail before activating the alarm relay
Relay output is activated when line test fail
Simple interfacing to any alarm panel, wired to any zone in your alarm
The Tele-Spy is designed to meet the CTR-21, AUSTEL approvals
Meets telephone standards requirements in order to prevent PSTN loading
Relay & visual signal when phone-line fails
Telephone Line Monitor is compatible with analog lines
Resets automatically when phone line is restored

Main Features

Test the phone line 24H
Advanced isolated electronics
New ultra compact design
Installer-Friendly none programming device
Build-in logic prevents false alarm
Easy and fast installation

Technical

Power Input: 9 – 16 Vdc
Current @ Standby: 15mA @ Active: 40mA at 12V
Tel. Line: Analog up to 55V
Fail indications: Relay & LED
Relay type: Solid state (N.C. and common)
Mounting: Printed board
Alarm Output Relay: N.C. 50mA/24V 27R in line resistor
Tamper Switch: None
Sensor: Electronic
RFI Protection: 30V/m, 10-1000MHz
EMI Protection: 40,000V low level lightning electrical interference
Operating Humidity: 95% non condensing max relative humidity
Operating Temperature: -10 to +60ºC (+14 to +140ºF)
Dimensions: 75 x 46 x 30 m”m (2.95 x 1.81 x 1.18“)
