Optical smoke detector AVP-402


Optical smoke detector with relay base

Professional optical smoke detector with relay base
Relay base is simpler to interface to burglary alarm panels
Optical smoke with internal sounder activated at alarm
Micro processor based optical smoke detector
With self test button
Advanced optical chamber minimize false alarm
Detector sensing smoke from burning of various materials
Circuitry overcome dust accumulation in the optical chamber
Build of main smoke head and base for fast servicing
Optical smoke is radioactivity free
Environment friendly optical smoke detector
Incorporates a pulsing LED located within the detector head
LED indicator: flickers during operation and latched on alarm
Optical smoke with output for remote indicator
Wide operation voltage 12-28V DC
Compatible with 12V alarm and 24V fire panels
Head and base supplied as set
International approvals
Best fit ceiling mounting
Base with build in relay
High RF and EMI Immunity
Size: 100 X 54 mm

SKU: AVP-402

Optical smoke detector with relay base

Professional optical smoke detector with relay base
Relay base is simpler to interface to burglary alarm panels
Optical smoke with internal sounder activated at alarm
Micro processor based optical smoke detector
With self test button
Advanced optical chamber minimize false alarm
Detector sensing smoke from burning of various materials
Circuitry overcome dust accumulation in the optical chamber
Build of main smoke head and base for fast servicing
Optical smoke is radioactivity free
Environment friendly optical smoke detector
Incorporates a pulsing LED located within the detector head
LED indicator: flickers during operation and latched on alarm
Optical smoke with output for remote indicator
Wide operation voltage 12-28V DC
Compatible with 12V alarm and 24V fire panels
Head and base supplied as set
International approvals
Best fit ceiling mounting
Base with build in relay
High RF and EMI Immunity
Size: 100 X 54 mm

Features and benefits

Fits most fire and alarm systems
Low current draw
High stability and sensitivity
Remote LED indicator output
Easy maintenance

Technical

Operating Voltage: 11-28V DC
Current Consumption;
Quiescence mode: 320 µA
Alarm mode (without auxiliary indicators): 2.6 mA
Alarm mode (with auxiliary Indicators): 35 mA
Sensitivity Range: 2 – 2.5%/foot obscuration
Sounder: Internal, 85 db @ 1 meter
Relay: N.O, N.C. and COM, 1A @ 30V
Alarm mode: Active until reset
Testing: Not available
Current to auxiliary indicators: 50 mA
Indication: Red LED
Color: Snow White
Enclosure material: ABS
Diameter: 100 mm including base
Height: 54 mm including base and LED
Operating Temperature: -10°C – +60°C (14°F – 140°F)
Relative Humidity Range: 10% – 93% non-condensing
