GSM gate opener professional


GSM gate opener AVG-10G

The GSM gate opener is a wireless remote control device
User remotely control gates, doors and barriers via mobile phone
Gate open from anywhere in the world
The GSM gate opener is an innovative GSM system based on caller ID identification
Features and phone numbers entered by SMS or PC
Log report and remote programming via PC and GSM modem
Supports up to 2000 accounts: 1600+400 special phone numbers Special numbers schedule
authorization time and days
Activated by mobile or land line phones
Slim size to fit in small space cabinets
Programming by SMS, SMS confirmation during program mode
Programming via PC and modem allows accounts Excel file import
Log report and remote programming via PC and GSM modem (not included)
GSM gate opener with relay output for gate or door activation
Powered by the gate power supply or simple wall plug 12V DC adapter
Features and phone numbers entered by SMS or PC
Simple installation, easy to attaches to wall or for any DIN rail
RF section with Quad band: GSM 850/900/1800/1900 MHz
High immunity to RFI and EMI interference

SKU: AVG10G e

GSM gate opener AVG-10G

The GSM gate opener is a wireless remote control device
User remotely control gates, doors and barriers via mobile phone
Gate open from anywhere in the world, call the number at no charge
The GSM gate opener is an innovative GSM system based on caller ID identification
Features and phone numbers entered by SMS or PC
Log report and remote programming via PC and GSM modem
Supports up to 2000 accounts: 1600+400 special phone numbers Special numbers schedule
authorization time and days
Activated by mobile or land line phones
Slim size to fit in small space cabinets
Programming by SMS, SMS confirmation during program mode
Programming via PC and modem allows accounts Excel file import
Log report and remote programming via PC and GSM modem (not included)
GSM gate opener with relay output for gate or door activation
Powered by the gate power supply or simple wall plug 12V DC adapter
Features and phone numbers entered by SMS or PC
Simple installation, easy to attaches to wall or for any DIN rail
RF section with Quad band: GSM 850/900/1800/1900 MHz
High immunity to RFI and EMI interference

Main Features

Supports 2000 accounts
High immunity RFI and EMI interference
Low Standby current consumption only 120 mA
Simple programming
Two Indication LEDs
Easy and fast installation

Technical

GSM frequency: 850/900/1800/1900 MHz
Supply voltage: 12V DC, 1.5A
Standby current consumption: 120mA
Antenna: SMA connector
SIM card: Standard size
PC interface: RS232
Wires interface: Power connector
Installation: Screws or DIN rail
Output type: Dry contact relay, rated 24V 2A
Authorized users: 2000
Event Buffer: 500
RFI Protection: 30V/m @ 10–1000 MHz
EMI Protection: 50KV @ 1 mS lightning or surge
Indications: Two colored LEDs
Enclosure: ABS box
Operating Temp: -25 to +60 C° (-13 to 140° F)
Humidity: 80%
Dimensions: Dimension: 98 x 82 x 30 mm (3.85 x 3.22 x 1.18″)

Technical – Four zones expandable GSM Alarm

On-board zones: 4
Expandable: 8 hardwired zones
PGM outputs: 2
Siren output: One fused
Keypad: Digital LED
Keypads support: 4
Remote key: RF or Key Switch
Remote arm/disarm: Mobile DTMF
Remote Wi-Fi arming: Optional with AVSWF4
Communication: PSTN and GSM
Central station reporting: Contact ID to 1-2 centers
Expand to GSM: GisMo module
Voice message: Optional by SVM
Smoke reset: Not available
Events buffer: 250
User codes: 34 plus codes locker
Operating temperature: -20 to +60º C
Enclosure: ABS box
Dimensions: 23 X 31 X 9 cm (9” X 12 1/4” X 3 1/2)
